The wiring loom is supplied in three sections, enabling you to fit it easily and conveniently as you complete each phase of your project.
What's in the box:
Complete wiring loom
Colour coded wiring
All relays
Fuse box(s)
Fully terminated
Instructions
The Interior Wiring Loom is designed as a stand-alone wiring loom interconnecting with the Front/engine Loom and the Rear Loom using multiway connectors thus enabling you to fit all three looms independently, connecting them all together when complete.
Wiring in the Interior loom enables the fitting of the following options:
All Instruments including Smiths Instruments option
All Warning Lights
Power Steering
Power socket for Sat Nav's & other accessories
Heater blower
Wiper motor
Engine management or Electronic Ignition system, power, earth and tacho take-offs
Switch options:
Sierra Column switches
Corsa Column switches
Traditional Toggle or Push/Pull switches
You supply your column switches- we wire them in
Fuse Box- This can be fitted inside the vehicle or through the bulk head with the fuses accessible from the engine bay
Relays- There are several relay options including Radiator fan, Horns, Indicator, Headlights and Starter
Engine/Front loom Layout:
Multi-connectors to interconnect with the Interior Loom
Bulkhead grommet
Wiring to instrument Senders, Alternator, Starter Motor, Horn(s), Radiator Fan & Lights
Engine Options:
Chevy
Ford
Rover V12
Other
Rear Loom:
Multi-connectors to interconnect with the Interior Loom. Bulkhead Grommet, Rear Lights, Fuel Pump, Electronic Speedo
Battery Lead Kit: (not included)
We can supply a complete battery lead kit for your installation. Our battery leads are available in black and red. They are very flexible and all terminals are professionally Hex crimped, soldered and heatshrunk.
We also include insulators and cable clips if required.
If you need a battery cut-off switch we can make your battery leads to accommodate this.
Standard or Race battery cut-off switches are available. Alternatively you could use a simple battery Negative Dis-connect Switch. This fits onto your battery negative standard round post terminal and then to your negative lead battery terminal without the need to cut or alter the battery cable.
Immobiliser: (not included)
We offer an immobiliser (ECS SCEXCEL) that can be integrated into your wiring loom. Easy to fit. Passive arming- 60 seconds after switching off ignition and removing the ignition key. Insurance Approved. IVA Approved.
